The DL151 diffuse tunnel light is engineered for use in linescan camera applications requiring indirect diffused light from multiple angles of incidence.

As part of Advanced illumination’s Expandable Series of lights. the DL151 is available in multiple lengths from 2” to 12” long.

The DL151 differs from the DL067 large area tunnel in being smaller, suitable for linescan based inspection applications, and has no options for port locations or size.

PCN No: 138

Date Issued: 7/11/17

Notice Type: Product Revision Change

Product Type: DL151

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the DL151 design. This change will result in a brighter, more uniform light at the same price*. Customers may still buy the current revision of this model until October 13th, 2017. After that time, orders for these products will be converted to their respective DL151 Revison A models.

This LED change will result in additional wavelengths being available: 455nm, 505nm, 660nm, 730nm, and 940nm.

*Visable and IR wavelengths that did not exist will prior will be sold at the same list price as similar wavelengths.

Orders for customized (dash numbers) versions of DL151 will be honored until January 12th, 2018. Ai will be actively working with customers for those products to simplify the transition.

Please contact your Ai Sales Representative if you have any questions.

PCN 138 DL151
