Compact High Intensity Spot Light

SL164

The SL164 spot light is designed to fit into smaller spaces at medium working distances, while still providing high intensity light on target. Multiple lens focus options are available, including narrow, medium and wide fan angles.

This light’s application flexibility is further enhanced by the addition of a “24” model that includes an embedded controller. This feature also makes the SL164 suitable for robotics applications where space and mounting options are restrictive, and allows for easier cable runs.

16 wavelength choices from 365nm UV to 940nm NIR, make this light a versatile, yet relatively inexpensive choice for many off-axis lighting applications.

Change Notice

PCN No: 129

Date Issued: June 15, 2016

Notice Type: Product Revision Change

Product Type: SL164

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the SL164 design. This change will result in a brighter, more uniform light at the same price*. Customers may still buy the current revision of this model until July 15th of 2016. After that time, orders for these products will be converted to their respective SL164 Revison A models.

This LED change will result in additional wavelengths being available: 365nm, 375nm, 385nm, 395nm, 405nm, 455nm, 470nm, 505nm, 530nm, 590nm, 625nm, 660nm, 730nm, 850nm and 940nm. Additionally the white LED color temperture will be changing from 6100K to 5500K.

*UV wavelengths (365nm, 375nm, 385nm, 395nm & 405nm) will be sold a higher list price, which will be released at the time of product introduction.

Orders for customized (dash numbers) versions of SL164 will be honored until December 16th of 2016. Ai will be actively working with customers for those products to simplify the transition.

Please contact your Ai Sales Representative if you have any questions.

PCN 129 SL164
