The MicroBrite RL208 is a compact, high-intensity ring light series, offering directional illumination that is suitable for both on-axis and off-axis applications.

This Bright Field ring light series provides uniform illumination and good detail on flat matte surfaces that also may have natural color variations.

The combination of multiple sizes and lens options allow for a wide variety of fields-of-view at various working distances.

As with most Advanced illumination products, this light family series is available with a variety of drive options, designed to fit most performance/price points.

PCN No: 132

Date Issued: June 24, 2016

Notice Type: Product Revision Change

Product Type: RL208

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the RL208 design. This change will result in a brighter, more uniform light at the same price*. Customers may still buy the current revision of this model until July 22th of 2016. After that time, orders for these products will be converted to their respective RL208 Revison A models.

This LED change will result in additional wavelengths being available: 365nm, 375nm, 385nm, 395nm, 405nm, 470nm, 505nm, 590nm, 660nm, 730nm, 850nm and 940nm. Additionally the white LED color temperture will be changing from 6100K to 5500K.

*UV wavelengths (365nm, 375nm, 385nm, 395nm & 405nm) will be sold a higher list price, which will be released at the time of product introduction.

Please contact your Ai Sales Representative if you have any questions.

PCN 132 RL208
