Classic Line Lights

LL163 Series

Our classic LL163 Line Lights are suitable for low intensity, low speed line scan applications.

These line lights are well established and have proven reliability.

Our classic LL163 Line Lights are suitable for low intensity, low speed line scan applications.

These line lights are well established and have proven reliability.

Provides a intensity level of 24kLux (working distance of 25mm).

Available in 7 wavelengths including 395nm (UV) and 880nm (IR).

Pre-engineered for expandability in 1.5” (38.1mm) increments up to 81” (2.06m).

LL163 derivatives include LL2912 (3”), LL3024 (6”) and LL3148 (12”) (which represent legacy part numbers)

Electrical Specifications
Color
24V Current
All Other Controls
625, 660, 880
0.03A per 1.5"
0.014A Max per 1.5"
395, 470, 520, WHI
0.02A per 1.5"
0.009A Max per 1.5"
Normal Operating Temperature
0 - 60°C
Weight
Per 3" - 226.8g (8.0oz)
Standard Cable Information
2 m long -0/+150 mm (80" -0/+6") - 105°C rated PVC jacket, foil shield with drain.
Photobiological Risk Factor
Exempt Applicable Wavelengths: 880
Group 1 (Low-Risk) Applicable Wavelengths: 470, 520, 625, 660, WHI
Group 2 (Moderate-Risk) Applicable Wavelengths: 395
Compliance
CE, RoHS, IEC 62471
IP Rating
IP50
Lumen Maintenance
L70 = 50,000 Hours
Datasheet
Inquire about this Product
Configure
+ Add To Wishlist
In Stock
LL2912A-WHIC1
