Built on the same architecture as the popular BL2 backlight, the FD2 planar diffuse light offers the same high-performance and flexible build options, but in a front lighting geometry.
The FD2 light differs from the FX and FX2 planar diffuse lights in that the LEDs are located under the diffuser, rather than positioned in the frame (side-illumination).
The FD2 planar diffuse light can be a substituted for a dome light on flat, and/or topographic surfaces, such as a PCB, depending on the exact features of interest. It has the distinct advantage over a diffuse dome light in that it can be positioned at much longer light working distances.
