Utilizing high power LEDs, the DL071 is engineered to provide uniform light for medium to large target area coverage.

The DL071 is best suited for inspection on curved surfaces where even illumination is necessary to avoid hot-spot reflections and where the working envelope is free of space constraints.

Similarly to the smaller DL194 and DL097 hemispherical domes, the DL071 is available in wide range of visible and NIR wavelengths, as well as a variery of control options.

PCN No: 141

Date Issued: 7/11/17

Notice Type: Product Revision Change

Product Type: DL071

Change Notification Summary

In an effort to improve our products, Advanced illumination (Ai) will update the LEDs used in the DL071 design. This change will result in a brighter, more uniform light at the same price*.

Customers may still buy the current revision of this model until October 13, 2017. After that time, orders for these products will be converted to their respective DL071 Revison A models. This LED change will result in additional wavelengths being available: 455nm, 505nm, 660nm, 730nm, and 940nm.

*Visable and IR wavelengths that did not exist will prior will be sold at the same list price as similar wavelengths. Orders for customized (dash numbers) versions of DL071 will be honored until January 12, 2018. Ai will be actively working with customers for those products to simplify the transition.

Please contact your Ai Sales Representative if you have any questions.

PCN 141 DL071
